KT-YTGD Series — All-in-One Solar Street Light

The KT-YTGD Series is Kototerk's flagship integrated solar street light, engineered for large-scale municipal and public road lighting projects. Combining the solar panel, LED light source, battery, and MPPT controller into a single compact unit, the YTGD delivers reliable, maintenance-free illumination with zero grid dependency.

Available in six power configurations: 30W / 40W / 60W / 80W / 100W / 120W Luminous output: 6,000 LM up to 24,000 LM Recommended installation height: 5m – 12m depending on model

Key Features

• High-Efficiency LED — 200 LM/W efficacy with 4-core SMD 3030 chips; luminous flux from 6,000 to 24,000 lumens across the range
• 23.8% Solar Panel Conversion — Monocrystalline panels from 50W to 150W maximize energy harvest even in low-sunlight conditions
• LiFePO4 Battery — Long-cycle lithium iron phosphate chemistry ensures 3–5 consecutive rainy days of backup operation and exceptional safety
• MPPT Controller — Maximum Power Point Tracking optimizes charging efficiency throughout the day
• Smart Lighting Control — Microwave motion sensing, segmented time scheduling, and intelligent dimming reduce energy consumption automatically
• Optional IoT Cloud Platform — Remote monitoring and management via centralized cloud platform; ideal for smart city and large municipal deployments
• Robust Construction — Die-cast + extruded aluminum housing with 1060 pure aluminum heat dissipation; IP65+ weather protection for tropical and extreme climates
• Wide Light Distribution — 75×155° beam angle with >95% lens transmittance for uniform road surface coverage

Specifications at a Glance

Ideal Applications

Municipal roads · Urban arterial streets · Residential communities · Industrial parks · Highways · Rural electrification projects · Smart city infrastructure
