Core Specification

Parameter Category	Core Parameter	Optional Configuration / Notes
Basic Info	Product Name	Standard Reflective Traffic Sign Pole / Road Signpost
	Application	Urban secondary roads, branch roads, industrial parks, scenic areas
	Design Standard	Compliant with GB 5768 and steel structure design codes
Structural Material	Main Material	Q235B/Q355B Carbon Structural Steel / Low Alloy High Strength Steel
	Surface Treatment	Hot-dip Galvanizing (zinc coating ≥85μm) + Fluorocarbon Painting / Pure Hot-dip Galvanizing
	Corrosion Life	20-30 years
Dimensions	Pole Type	Octagonal / Conical / Cylindrical
	Height	3m / 4m / 5m / 6m (customizable)
	Arm Length	0.8m / 1m / 1.5m (customizable)
	Pole Spec	Octagonal: 120×120mm~200×200mm, wall thickness 3-5mm
Sign Spec	Sign Material	Aluminum plate + reflective film (Class I/II/III optional)
	Reflective Grade	Engineering grade / High intensity grade / Super high intensity grade (GB/T 18833)
	Visibility	≥1000m daytime, ≥300m nighttime
Load & Safety	Wind Load	0.5~0.8kN/m² (12-level typhoon resistant)
	Seismic Grade	Grade 7-9
	Equipment Load	Max 30kg (reflective sign)
Functional Config	Auxiliary Facilities	Maintenance ladder, optional equipment cabinet, lightning rod
	Electrical Interface	None (reserved for solar sign if needed)
	Optional Features	Solar reflective module, active illumination module
Installation & Warranty	Installation	Flange foundation anchoring / embedded installation
	Warranty	1-3 years (lifetime for structure)

Our reflective traffic sign poles are built for long-term performance

High-Visibility Reflective Technology: Paired with aluminum signs and Class I/II/III reflective film (meeting GB/T 18833 standards), our signs offer 1000m+ daytime visibility and 300m+ nighttime visibility, ensuring clear guidance for all road users.
Robust & Corrosion-Resistant: Crafted from Q235B/Q355B hot-dip galvanized steel, the poles deliver 20–30 years of rust-proof performance and 12-level wind resistance, making them suitable for diverse climates and environments.
Flexible Customization: Available in octagonal, conical, or cylindrical profiles (height 3–6m, arm length 0.8–1.5m), with options for pure hot-dip galvanizing or fluorocarbon painting to match project aesthetics.
Low Maintenance: No electrical components required, reducing operational costs and ensuring hassle-free long-term use. Optional solar-powered reflective modules are available for enhanced nighttime visibility.

Choose Kototerk’s standard reflective traffic sign poles for a durable, cost-effective roadway signage solution. Get in touch to discuss your project needs and receive a tailored quote.
